ID INFO 500
HF | NFC 13.56 MHz
ID INFO 500
The ID INFO 500 is a compact HF reader designed to quickly display assigned locker numbers. Simply hold your card or wristband up to the reader, and the stored locker number appears directly on the integrated LED display. No additional queries via PC or app are required. The ID INFO 500 is ideal for gyms, wellness areas, swimming pools, leisure facilities, and companies using electronic locker locking systems from Ojmar or Burg.
.png)
.png)
Highlights
High-performance HF/NFC desktop reader
Support for Ojmar & BURG
Automatically reads the locker number stored on the medium and displays it immediately. Compatible with selected locker locks from BURG and Ojmar.
USB and Ethernet Connectivity
The USB interface enables easy connection to PC-based applications, while PoE (Power over Ethernet) provides an additional power supply option via the Ethernet cable for flexible installation
HID & VCP
Flexible data output via HID or Virtual COM Port enables integration into various system environments.
Up to 3 cm read range
Depending on the transponder used and the operating environment, the ID INFO 500 achieves a read range of up to 3 cm.
SDK for Windows
A Windows SDK and a binary command protocol support easy integration into custom applications.
Compact desktop housing
Compact design with an integrated antenna. No external antenna or complex installation required.
Product information
Technical details
The ID INFO 500 is a compact HF/NFC desktop reader with an integrated LED display, specifically designed to display locker numbers stored on electronic locker media from Ojmar (OTS 20 Basic, Advance, and Battery-free; OTS40 Battery-free) and Burg (Niro RFID; Flexxo; Corona 2). The device operates at a frequency of 13.56 MHz and supports MIFARE® Classic technology.
When a card or wristband is held in front of the reader, the ID INFO 500 automatically reads the stored locker number and displays it directly on the integrated screen. This allows the assigned locker number to be identified in seconds—without the need for additional software queries or complex operation.
Typical areas of application include fitness and wellness centers, swimming pools, spas, and leisure facilities with electronic locker locking systems from Ojmar or Burg.
ELECTRICAL SPECIFICATIONS
Power supplyUSB / PoE (Power over Ethernet)
Power consumption< 500 mA
Operating frequency HF / NFC: 13.56 MHz
Reading rangeHF / NFC: ≤ 3 cm
Supported locking systems OTS 20 Basic, Advance and battery-free
/ OTS40 battery-free / Niro RFID (BURG)
/ Flexxo (BURG) / Corona 2 (BURG)
Standard UID output ISO 14443A UID LSB
Antenna integrated
Status indicator 1 buzzer
InterfaceUSB – VCP
Connections 120 cm cable with USB Type-A connector
MECHANICAL SPECIFICATIONS
Dimensions 130 × 95 × 30 mm excluding USB cable
Display dimensions 3 × 1.5 cm
Weight 142g
HousingABS (silver)
ENVIRONMENTAL CONDITIONS
Operating temperature -20 °C to +70 °C
Storage temperature-20 °C to +80 °C
Humidityup to 95% non-condensing
SUPPORTED STANDARDS / TAGS (RFID HF | NFC 13.56 MHz)
ISO 14443 A and compatible Read/Write:
MIFARE® Classic/1K
UID read only for all others
ISO14443A RFID tags
ISO 14443 B and compatible SRI4K, SRIX4K, AT88RF020,
66CL160S, SR176
SDK INFORMATION
Supported operating systems Windows 10, Windows 11
Supported programming languages Binary command protocol, VS2005 C++
Demo software Windows
